INTRAPUR PLUS I.V.FILTER 0.2MICRON
Back
4099800
INTRAPUR PLUS I.V.FILTER 0.2MICRON
Lisa ostukorvi lõik
Spetsifikatsioonid
Dokumendid
Infusion filters
Application
Filter
Brand name
Intrapur®
Product name (HC)
Intrapur® Plus
Charge
positive
Type of filter
Fluid filter, Bacteria filter
Position of filter
Inline
Pore size (Bacteria filter)
0.2 µm
with tube
Yes
Inner-ø tube
2.00 mm
Outer-ø tube
4.10 mm
Filling volume incl. tubing
3.50 ml
Application time
96 hours
Flow control device
-
Filter area
10.00 cm2
Priming volume filter housing
2.40 ml
Flow rate
30.00 ml/min
maks rõhk
2.0 bar
Connection
Luer-Lock/male, Luer-Lock/female
Type of packaging
Blister
Tüüp
Yes
Tüüp
No
Tüüp
No
Tüüp
No
Tüüp
No
Tüüp
No
Product contains PVC
Yes
Tüüp
No
Product contains DEHP
No
Product contains Nickel
No
Materjal
disposable
Tüüp
sterile
Tüüp
EO
